Mô tả

1. Applications:

Widely used in:

• Pre-filtration in HVAC systems, paint booths, ventilation fans, air conditioning units.

• Used as pre-filter before medium/HEPA filters.

• Electronics, food processing, pharmaceutical and cleanroom industries.

• Can also be used as media for filter bags or filter panels.

2. Specifications:

• Material: 100% polyester or polypropylene (PP) synthetic fibers.

• Structure: Thermally bonded non-woven fabric, consistent fiber distribution.

• Color: White (can vary depending on model – green, gray, carbon-coated).

• Filtration level: Coarse dust, particles ≥ 5 µm.

• Thickness options: 5 mm, 10 mm, 20 mm.

• Popular roll sizes:

  • 2000 x 20000 x 5 mm

  • 2000 x 20000 x 10 mm

  • 2000 x 20000 x 20 mm

  • 1400 x 20000 x 10 mm

  • 1400 x 20000 x 20 mm

  • Can be cut to custom widths as required.

• Recommended air velocity: 1.5 – 2.5 m/s

• Initial resistance: 20 – 45 Pa (depending on thickness)

• Max temperature: Up to 80°C

3. Advantages:

• Lightweight, easy to install and transport.

• Can be cut to any size, fits all filter frames or equipment.

• Cost-effective and easy to replace.

• No fiber shedding, prevents secondary contamination.
