Mô tả

1. Applications:

Mini-pleat HEPA filters are widely used in environments requiring high cleanliness levels, such as:

• Cleanrooms in electronics, pharmaceutical, and food industries.

• HVAC systems in hospitals, operating rooms, and laboratories.

• Residential and industrial air purification systems.

2. Technical Specifications:

• Filtration Efficiency: From 99.97% to 99.999% for particles ≥ 0.3 microns.

• Filter Class: H13, H14 (according to EN 1822 standard).

• Media Material: Ultra-fine glass fiber.

• Frame Material: Aluminum, galvanized steel, or stainless steel.

• Gasket: EPDM, PU, or neoprene.

• Operating Temperature: Up to 80°C.

• Design: Mini-pleat structure increases filter surface area and reduces initial pressure drop.

• Size: Customizable according to customer requirements to fit different systems and installation spaces.

3. Advantages:

• Compact size, easy installation in limited spaces.

• High filtration efficiency, suitable for stringent cleanliness requirements.

• Long service life, reducing maintenance and replacement costs.

• Mini-pleat design lowers initial pressure drop, saving energy.

• Flexible sizing to meet diverse installation needs.
