Mô tả

1. Applications:

Used in:

• HVAC systems (AHU, FCU), cleanrooms, hospitals, electronics, pharma, food factories.

• Pre-filtration before HEPA filters.

• Medium-level air filtration applications.

2. Technical Specifications:

• Filter Class: M5–M6, F5–F8 (EN779), 40–90% efficiency.

• Media: Synthetic fiber or glass fiber.

• Frame: Galvanized steel, aluminum, or ABS.

• Common Sizes:

  • 594 x 594 x 292 mm

  • 594 x 287 x 292 mm

  • Custom sizes available upon request

• Thickness options: 46 mm, 69 mm, 292 mm, etc.

• Airflow capacity: 1000 – 3000 m³/h (depending on size).

• Initial pressure drop: ~250 Pa.

• Max temp: 80°C

• Installation: Slide-in rails or clip lock.

3. Advantages:

• Strong, durable frame.

• Stable performance with minimal leakage.

• Easy to install, replace, and maintain.

• Custom-fit to any system design or space.
